The VM090D is a Microwave Monolithic Integrated Circuit (MMIC) designed in HEMT (High Electron Mobility Transistor) structure for operating frequency range from 8.5 to 10.5GHz.
The MMIC is developed on 250nm GaN/SiC process and is internally matched through 50Ω RF accesses. It can provide an output power up to 20W and associated power added efficiency of 32% in pulsed mode.
VM090D
8.5 to 10.5GHz - 20W
GaN/SiC Power Amplifier
GaN/SiC Power Amplifier
POWER AMPLIFIERS > 3W
DatasheetFeatures
- Frequency range 8.5 – 10.5GHz
- Output Power 43dBm @Pin = 23dBm
- PAE 32% @Pin = 23dBm
- Linear Gain 27dB
- DC bias VD = +28V, lDQ = 190mA, VG = -2.35V (Typical)
- Chip size 5×1.7×0.1(mm)
